"Quality initial, Honesty as base, Sincere company and mutual profit" is our idea, so that you can create consistently and pursue the excellence for RO Series Brackish/Grey Water Reverse Osmosis Membrane Element, To acquire a consistent, profitable, and constant advancement by getting a competitive advantage, and by continuously increasing the benefit added to our shareholders and our employee.
"Quality initial, Honesty as base, Sincere company and mutual profit" is our idea, so that you can create consistently and pursue the excellence for Reverse Osmosis Membrane, All of our items comply with international quality standards and are greatly appreciated in a variety of markets around the world. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients in the near future.
Large Flux Reverse Osmosis ( RO ) Membrane TFC-3213-1000G is a new product, Our pursuit and enterprise aim would be to "Always fulfill our buyer requirements". We'll offer the finest high quality, probably the most industry-competitive selling price, for each and every new and outdated consumer while using the most excellent green expert services.
HIDTM Commercial Membrane ranks the best brands in China among the RO membrane industry. Reverse Osmosis Membrane has won the trust of numerous clients for feeding the reliable purified water over 10 years. Each membrane is made of HID developed & pre-examined sheet and goes through stringent making processes as well as in-house quality inspection & testing before delivery. HID Membrane has been certified by SGS & China Jiangsu Sanitation Bureau wrt drinking water membrane elements.
Model No. | Min. Salt Rejection (%) | Stabilized Salt Rejection(%) | Permeate Flow Rate(gpd) | TestTemp. | Test Pressure | Test Water TDS |
TFC-3012-200 | 95 | 97 | 200 | 25℃ | 65psi | 500ppm |
TFC-3012-300 | 95 | 97 | 300 | 25℃ | 65psi | 500ppm |
TFC-3012-400 | 95 | 97 | 400 | 25℃ | 80psi | 500ppm |
TFC-3013-400 | 95 | 97 | 400 | 25℃ | 100psi | 500ppm |
TFC-3012-500 | 94 | 96 | 500 | 25℃ | 100psi | 500ppm |
TFC-3213-600 | 94 | 96 | 600 | 25℃ | 100psi | 500ppm |
TFC-3213-800 | 94 | 96 | 800 | 25℃ | 100psi | 500ppm |
TFC-3213-1000 | 94 | 96 | 1000 | 25℃ | 100psi | 500ppm |
1. Permeate flow rate and salt rejection is based on testing conditions: 25℃, PH 7.5, 20% recovery.
2. Stabilized salt rejection is generally achieved within 24-48 hours of continuous use, depending upon feedwater characteristics and operating conditions.
Model No. | Maximum Operating Temperature |
Maximum Operating Pressure |
Feed Water PH Range, continuous operation |
Maximum Feed Water Turbidity |
Maximum Feed Water SDI |
Chlorine Tolerance |
TFC-3012-200 | 45℃ | 200psi | 4-11 | 1NTU | 5 | <0.1ppm |
TFC-3012-300 | 45℃ | 200psi | 4-11 | 1NTU | 5 | <0.1ppm |
TFC-3012-400 | 45℃ | 200psi | 4-11 | 1NTU | 5 | <0.1ppm |
TFC-3013-400 | 45℃ | 200psi | 4-11 | 1NTU | 5 | <0.1ppm |
TFC-3012-500 | 45℃ | 200psi | 4-11 | 1NTU | 5 | <0.1ppm |
TFC-3213-600 | 45℃ | 200psi | 4-11 | 1NTU | 5 | <0.1ppm |
TFC-3213-800 | 45℃ | 200psi | 4-11 | 1NTU | 5 | <0.1ppm |
HID RO Membranes are widely used in ultra-pure water, process pure water, cooling tower water, boiler water supply, pure water, throughout the electronics industry, optoelectronic industry, machinery manufacturing, fine chemical industry, medical pharmaceutical, food, and beverage industry, surface coating, and many other industries.
