Leading Manufacturer for Malaysia Outdoor Water Filter - 4″ FRP pressure vessel/ 4040 FRP Membrane Housing/ Brackish Water/ Commercial Use – HID Membrane Detail:

FRP filament winding pressure vessel is for reverse osmosis application and adopts the world advanced technology and technique to manufacture high-quality membrane pressure vessel products. FRP membrane housing is increasingly favored in Water Treatment Industry applying in Drinking Water, Food & Beverage industry, Petro‐Chemical Industries, Power industry, and Seawater desalination, etc. Our products have been distributed worldwide such as Middle East, S.E Asia, Iran, Australia, and India. The product is available in both end entry and side entry configuration; pressure rating from 150 psi to 1200 psi and length from 1 through 7 membrane elements.

HID ro membrane

Specifications	End port
Available pressure rating (psi)	250/ 300/ 450/ 1000
Length (No. of elements)	1 to 4
Main Material	FRP
Color	White (other colors are available on request)
Head assembly	Included
Adaptor	N/A
Straps and saddles	Included
Packaging	PVC plastic wrapping with carton outer pack
Max. operating Temp	49℃ (120℉)

Note: Head assembly consists of half-moon lockplates, ABS seal plate and lock nut, Head seal, permeate port o‐ring. (cast Aluminum bearing plate only used in 1000 psi vessel) *0.75” OD standard adaptor is provided for side entry vessel. Adaptors of different dimensions are available on request.

Model	PSI	Connection	Membrane size	Number of elements
2521	300	End Port	2521	1
2540	300	End Port	2540	1
4040-250	250	Side Port/End Port	4040	1-4
4040-300	300	Side Port/End Port	4040	1-4
4040-450	450	Side Port/End Port	4040	1-4
4040-1000	1000	Side Port/End Port	4040	1-4
8080-150	150	Side Port/End Port	8040	1-7
8080-250	250	Side Port/End Port	8040	1-7
8080-300	300	Side Port/End Port	8040	1-7
8080-450	450	Side Port/End Port	8040	1-7
8080-600	600	Side Port/End Port	8040	1-7
8080-800	800	Side Port/End Port	8040	1-7
8080-1000	1000	Side Port/End Port	8040	1-7
8080-1200	1200	Side Port/End Port	8040	1-7
