10000LPH Reverse Osmosis (RO) System for Industrial RO Plant

Short Description:

10000L/H Reverse Osmosis (RO) system equipment high performance with competitive price fully automatic working Tap water, well water, river water etc.

Capacity: 10000 LPH

Source of Water: Tap water, underground water, lake water

OEM/ODM: Accept

Manufacturer: Yes

Delivery Time: 2-7 days

Shipping Support: Express / Sea/ Land/ Air freight

Place of Origin: Jiangsu, China

E-mail: info@ro-hid.com

Send email to us Download as PDF

Product Detail

Company Profile

Product Tags

10000L/H Reverse Osmosis system high performance with competitive price fully automatic working Tap water, well water, river water, etc for industrial RO plant. Inlet TDS<2000PPM, continuous operation, high quality, no need to use acid regeneration, save the recoil and cleaning water, ultrapure water produced in high yield (up to 95% yield), High recovery rate, low rate of wastewater, high water utilization efficiency, no reserves and acid diluted acid transport facilities, reducing the shop floor area, the use of safe and reliable, to avoid worker contact with acid, reduce operation and maintenance costs, easy installation, low installation cost.

Industrial RO plant

Reverse Osmosis System Specification:

Product Name	RO 250LPH	RO 500LPH	RO 2000LPH	RO 10000LPH
OEM/ODM	Accept
Input Water TDS	< 2000PPM
Output Water Capacity (l/h)	250	500	2000	10000
Power	220V 50Hz	220V 50Hz	220V 50Hz	380V 50Hz
Raw Water Type	Municipal water, well water, underground water, etc
Process	Raw water tank--raw water pump--sand filter--carbon filter--cartridge filter--high-pressure pump-- RO system-production water tank.

10000LPH （Standard）

1.1 Raw water type: Tap water, well water, river water, etc
1.2 Inlet TDS<2000PPM.
1.3 Power: 220V 50Hz

No.	Product Name	Specifications	Material	QTY	Remarks
1	raw water tank provided by the customer	5000L	PE	1 piece	PE One-time molding
2	Stainless steel liquid control system	OEM	304	1 set	Floating ball type with signal output
3	Raw water flow meter	Raw water flow meter	0-16m³/H	Pipeline	1 set
4	Raw water valve	DN50mm	Upvc	1 piece	Food grade valve
5	Pressure gauge	0-0.4Mpa		1 piece
6	Raw water booster pump	Q:16m³/h；H:30M	304	1 set	380V 50HZ
7	Raw water solenoid valve	UW50	copper	1 set	220V
8	multi-media filter	HXSF-1000mm	FRP	1 set	Specially made, lined with PE
9	influent distribution system	Above Below	UPVC	1 set
10	pipe valve	DN15-50MM	UPVC	1 set
11	quartz sand	4-60		1 set
12	activated carbon filter	HXSF-1000mm	FRP	1 set	Specially made, lined with PE
13	influent distribution system	Above Below	UPVC	1 set
14	pipe valve	DN15-50MM	UPVC	1 set
15	Purified water carbon (coconut carbon)			1 set
16	stainless steel valve	OEM	stainless	1 set
17	Dosing system	Scale inhibitor addition		1 set
18	precision filter	HXUF	stainless	1 set
19	Filter	5U*1000mm	PP	1 set
20	RO membrane	8040	polymer	10 set
21	membrane housing	8040	FRP	3 set
22	high-pressure pump	Q:16m³/h；H:120M	stainless	1 set	380V 50HZ
23	concentrated water flowmeter	0-16 m³/H	Pipeline	1 set
24	pure water flowmeter	0-10m³/H	Pipeline	1 set
25	concentrated water control valve	DN50mm	304	1 piece
26	pure water tank self-contained	5000L	PE	1 piece
27	stainless hydraulic control system	OEM	304	1 set	floating bead, the output signal
28	conductance instrument	CM-230K		1 set	Online detection and display
29	high voltage protection	-0.1-0.3Mpa	specially made	1 set
		0-2.5Mpa		1 set	Protect the high-pressure pump and membrane
		0-1.6Mpa		1 set
30	Mainframe system	OEM	stainless	complete set
31	electric cabinet			1 set
32	electric control system			1 set	low voltage electrical apparatus,electrotechnical box,etc
33	PLC control			1 set
34	plumbing	Including flow meter and pressure gauge	UPVC	1 set	Food grade sanitary pipe
