Factory making House Water Purifier - RO Membrane TFC-3213-800 GPD – HID Membrane Detail:

ROMembrane Price

HID^TM Commercial Membrane ranks the best brands in China among RO membrane industry. It has won the trust of numerous clients for feeding the reliable purified water over 10 years. Each membrane is made of HID developed & pre-examined sheet and goes through stringent making processes as well as in-house quality inspection & testing before delivery. HID Membrane has been certified by SGS & China Jiangsu Sanitation Bureau wrt drinking water membrane elements.

HID ro membrane

Model No.	Min. Salt Rejection (%)	Stabilized Salt Rejection(%)	Permeate Flow Rate(gpd)	TestTemp.	Test Pressure	Test Water TDS
TFC-3012-200	95	97	200	25℃	65psi	500ppm
TFC-3012-300	95	97	300	25℃	65psi	500ppm
TFC-3012-400	95	97	400	25℃	80psi	500ppm
TFC-3013-400	95	97	400	25℃	100psi	500ppm
TFC-3012-500	94	96	500	25℃	100psi	500ppm
TFC-3213-600	94	96	600	25℃	100psi	500ppm
TFC-3213-800	94	96	800	25℃	100psi	500ppm

1. Permeate flow rate and salt rejection is based on testing conditions: 25℃, PH 7.5, 20% recovery.
2. Stabilized salt rejection is generally achieved within 24-48 hours of continuous use, depending upon feedwater characteristics and operating conditions.

Model No.	Maximum Operating Temperature	Maximum Operating Pressure	Feed Water PH Range, continuous operation	Maximum Feed Water Turbidity	Maximum Feed Water SDI	Chlorine Tolerance
TFC-3012-200	45℃	200psi	4-11	1NTU	5	<0.1ppm
TFC-3012-300	45℃	200psi	4-11	1NTU	5	<0.1ppm
TFC-3012-400	45℃	200psi	4-11	1NTU	5	<0.1ppm
TFC-3013-400	45℃	200psi	4-11	1NTU	5	<0.1ppm
TFC-3012-500	45℃	200psi	4-11	1NTU	5	<0.1ppm
TFC-3213-600	45℃	200psi	4-11	1NTU	5	<0.1ppm
TFC-3213-800	45℃	200psi	4-11	1NTU	5	<0.1ppm
